KENWOOD ProTalk TK-3401D
The new TK-3401D changes the game – a new digital PMR446 radio with 16 separate digital channels, increased range, clarity and security and leadership in its field.
Key Features
• Digital / Analogue Compatibility
• User-friendly – No License Required
• High-quality audio, powerful output
• A High-Capacity Battery for Long-Lasting Operation
Other Features
• Dual mode (user selectable analogue/digital) hand portable built on the dPMR446 protocol
• FDMA 4-Level FSK modulation enables highly efficient 6.25 kHz frequency use compared with analogue 12.5 kHz PMR446 radios
• Double the usable channels against current analogue PMR446 radios for congestion-free communications:
32-ch/2-zone (16ch per Zone) @ ERP 500 mW RF output
Zone 1: PMR446 16ch (446.000-446.100MHz)
Zone 2: dPMR446 16ch (446.100-446.200MHz)
• Extended range and improved radio interference performance
• Loud and clear digital communications with AMBE+2 vocoder and our new 1.0W BTL amplifier
• User programmable features without requiring software
• Rugged and durable Kenwood quality
| Specifications | |
|---|---|
| Frequency Range | Analogue – 446.0 to 446.1 MHz Digital – 446.1 to 446.2 MHz |
| Number of Channels | 32 ch / 2 zone |
| Channel Spacing | Analogue – 12.5 kHz Digital – 6.25 kHz |
| Operating Voltage | 7.5 V DC±20% |
| Battery Life | ~ 14 hours |
| Operating Temperature Range | -30°C to +60°C |
| Frequency Stability | ± 1.0 ppm |
| Dimensions (W x H x D) | 54 x 122 x 35.5 mm |
| Weight | 165 g |
| RF Power output | 500 mW |
| Audio Output | Internal speaker – 1 W / 12 Ω External output – 500mW /8 Ω |
| Modulation | Narrow – 8K50F3E Very Narrow – 4K00F1E |
